Home » Products » POWER MODULE » AC-DC Power Module » 15W AC DC Power Module
YSM20 15W Series
Rated Power: 15W
Input: 100-240V AC, 50 / 60Hz
Standby Power: ≤0.1W
Class Ⅱ isolation level
Protection: Short Circuit, OCP, OVP
Output: 3.3-24V
Three Year Warranty
Model No. | YSM20–0333500 | YSM20–0503000 | YSM20–1201250 | YSM20–1501000 | YSM20-2400630 |
Dc voltage | 3.3V | 5V | 12V | 15V | 24V |
Rated current | 3.5A | 3A | 1.25A | 1A | 0.63A |
Rated power(Max) | 11.55W | 15W | 15W | 15W | 15.12W |
Ripple & Noise(Max) | 200mvp-p | 200mvp-p | 200mvp-p | 200mvp-p | 200mvp-p |
Input voltage | 90 ~ 264VAC 50/60Hz | ||||
Inrush current | Cold Start 20A/115VAC 45A/230VAC | ||||
Effciency | 74% | 78% | 82% | 82% | 82% |
working Temperature | -30~+70℃(Refer to “ Derating curve’“) | ||||
withstand voltage | I/P-O/P:3KVAC | ||||
protection | Short Circuit/Over Load/Over Voltage | ||||
connection | I/P:2 pins , O/P:2 pins |
