YSM60 60W Series
Rated Power: 60W
Input: 90-264VAC, 50 / 60Hz
Standby Power: ≤0.1W
Class Ⅱ isolation level
Protection: Short Circuit, OCP, OVP
Output: 5-48V
Three Year Warranty
| Model No. | YSM60-05010000 | YSM60-12005000 | YSM60-15004000 | YSM60-24002500 | YSM60-48001250 |
| Dc voltage | 5V | 12V | 15V | 24V | 48V |
| Rated current | 10A | 5A | 4A | 2.5A | 1.25A |
| Rated power(Max) | 50W | 60W | 60W | 60W | 60W |
| Ripple ＆ Noise(Max) | 80mvp-p | 120mvp-p | 120mvp-p | 150mvp-p | 240mvp-p |
| Input voltage | 90 ~ 264VAC 50/60Hz | ||||
| Inrush current | Cold Start 30A/115VAC 60A/230VAC | ||||
| Eficiency | 84% | 87.5% | 89% | 90% | 91% |
| working Temperature | -30~+70℃(Refer to “ Derating curve’“) | ||||
| withstand voltage | I/P-O/P:4KVAC | ||||
| protection | Short Circuit/Over Load/Over Voltage | ||||
| connection | I/P:2 pins ， O/P:2 pins | ||||
