YS35B Series
Energy efficiency level Vl
Class ll Power Supply
3 Years Warranty
Universal AC input/Full range
No load power consumption < 0.1W
Protections: Short Circuit /Over Load /Over Voltage
-20~+60℃wide range working temperature
| Model | Order P/N | YS35- 0905330B-D1J |
YS35- 1204000B-D1J |
YS35- 1503200B-D1J |
YS35- 2402000B-D1J |
YS35- 3601330B-D1J |
YS35- 4801000B-D1J |
| Safety Model No. | YS35-0905330 | YS35-1204000 | YS35-1503200 | YS35-2402000 | YS35-3601330 | YS35-4801000 | |
| Output | DC Voltage | 9V | 12V | 15V | 24V | 36V | 48V |
| Rated Current | 5.33A | 4A | 3.2A | 2A | 1.33A | 1A | |
| Rated Power | 48W | 48W | 48W | 48W | 48W | 48W | |
| Ripple & Noise(max.) | 90mVp-p | 150mVp-p | 200mVp-p | 240mVp-p | 360mVp-p | 400mVp-p | |
| Voltage Tolerance | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | |
| Line Regulation | ± 3% | ± 3% | ± 3% | ± 3% | ± 3% | ± 3% | |
| Load Regulation | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | |
| Setup,Rise,Hold up Time | 1.0s,50ms,30ms/230VAC(at full load) 2.0s,50ms,18ms/115VAC(at full load) | ||||||
| Input | Rated Voltage Range | 100-240VAC | |||||
| Voltage Range | 90-264VAC | ||||||
| Frequency Range | 50/60Hz | ||||||
| AC Current | 0.9A/115VAC 0.6A/230VAC | ||||||
| Inrush Current | Cold Start 50A/200us at 230VAC 50Hz Cold Start 30A/200us at 115VAC 50Hz | ||||||
| Leakage Current | <0.25mA/230VAC | ||||||
| Efficiency | 87.8% | 88% | 88% | 88.5% | 89% | 89.5% | |
| No Load Power Consumption | <0.1W | ||||||
