YS16B Series
Energy efficiency level Vl
Class ll Power Supply
3 Years Warranty
Universal AC input/Full range
No load power consumption < 0.1W
Protections: Short Circuit /Over Load /Over Voltage
-20~+60℃wide range working temperature
| Model | Order P/N | YS16- 0503000B-D1J |
YS16- 0902000B-D1J |
YS16- 1201670B-D1J |
YS16- 1501200B-D1J |
YS16- 2400750B-D1J |
YS16- 3600500B-D1J |
| Safety Model No. | YS16-0503000 | YS16-0902000 | YS16-1201500 | YS16-1501200 | YS16-2400750 | YS16-3600500 | |
| Output | DC Voltage | 5V | 9V | 12V | 15V | 24V | 36V |
| Rated Current | 3A | 2A | 1.5A | 1.2A | 0.75A | 0.5A | |
| Rated Power | 15W | 18W | 18W | 18W | 18W | 18W | |
| Ripple & Noise(max.) | 75mVp-p | 120mVp-p | 150mVp-p | 200mVp-p | 240mVp-p | 360mVp-p | |
| Voltage Tolerance | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | |
| Line Regulation | ± 3% | ± 3% | ± 3% | ± 3% | ± 3% | ± 3% | |
| Load Regulation | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | |
| Setup,Rise,Hold up Time | 1.0s,60ms,20ms/230VAC(at full load) 2.5s,60ms,12ms/115VAC(at full load) | ||||||
| Input | Rated Voltage Range | 100-240VAC | |||||
| Voltage Range | 90-264VAC | ||||||
| Frequency Range | 50/60Hz | ||||||
| AC Current | 0.6A/115VAC 0.3A/230VAC | ||||||
| Inrush Current | Cold Start 50A/200us at 230VAC 50Hz Cold Start 30A/200us at 115VAC 50Hz | ||||||
| Leakage Current | <0.25mA/230VAC | ||||||
| Efficiency | 82% | 85% | 85.5% | 85.5% | 86% | 87% | |
| No Load Power Consumption | <0.1W | ||||||
