YS6E Series
Energy efficiency level Vl
Class ll Power Supply
3 Years Warranty
Universal AC input/Full range
No load power consumption < 0.1W
Protections: Short Circuit /Over Load /Over Voltage
-20~+70℃ wide range working temperature
| Model | Order P/N | YS6E- 0501200-D1J |
YS6E- 0601000-D1J |
YS6E- 0750800-D1J |
YS6E- 0900600-D1J |
YS6E- 1200500-D1J |
YS6E- 2400250-D1J |
YS6E- 3600160-D1J |
| Safety Model No. | YS6E-0501200 | YS6E-0601000 | YS6E-0750800 | YS6E-0900600 | YS6E-1200500 | YS6E-2400250 | YS6E-3600160 | |
| Output | DC Voltage | 5V | 6V | 7.5V | 9V | 12V | 24V | 36V |
| Rated Current | 1.2A | 1A | 0.8A | 0.6A | 0.5A | 0.25A | 0.16A | |
| Rated Power | 6W | 6W | 6W | 5.4W | 6W | 6W | 5.76W | |
| Ripple & Noise(max.) | 75mVp-p | 75mVp-p | 90mVp-p | 90mVp-p | 120mVp-p | 240mVp-p | 300mVp-p | |
| Voltage Tolerance | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | |
| Line Regulation | ± 3% | ± 3% | ± 3% | ± 3% | ± 3% | ± 3% | ± 3% | |
| Load Regulation | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | |
| Setup,Rise,Hold up Time | 1.0s,30ms,30ms/230VAC(at full load) 2.0s,30ms,12ms/115VAC(at full load) | |||||||
| Input | Rated Voltage Range | 100-240VAC | ||||||
| Voltage Range | 90-264VAC | |||||||
| Frequency Range | 50/60Hz | |||||||
| AC Current | 0.2A/115VAC 0.15A/230VAC | |||||||
| Inrush Current | Cold Start 65A/200us at 230VAC 50Hz Cold Start 30A/200us at 115VAC 50Hz | |||||||
| Leakage Current | <0.25mA/230VAC | |||||||
| Efficiency | 75% | 79% | 79% | 78.5% | 80% | 80% | 80.5% | |
| No Load Power Consumption | <0.1W | |||||||
