YS40C-E Series
Energy efficiency level Vl
Class ll Power Supply
3 Years Warranty
Universal AC input/Full range
No load power consumption < 0.1W
Protections: Short Circuit /Over Load /Over Voltage
-20~+50℃wide range working temperature
| Model | Order P/N | YS40C- 0904000E-D1J |
YS40C- 1204000E-D1J |
YS40C- 2402000E-D1J |
YS40C- 3601330E-D1J |
YS40C- 4801000E-D1J |
| Safety Model No. | YS35V-0904000 | YS35V-1203000 | YS35V-2401500 | YS35V-3601330 | YS35V-4801000 | |
| Output | DC Voltage | 9V | 12V | 24V | 36V | 48V |
| Rated Current | 4A | 4A | 2A | 1.33A | 1A | |
| Rated Power | 36W | 48W | 48W | 48W | 48W | |
| Ripple & Noise(max.) | 90mVp-p | 120mVp-p | 200mVp-p | 300mVp-p | 400mVp-p | |
| Voltage Tolerance | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | |
| Line Regulation | ± 3% | ± 3% | ± 3% | ± 3% | ± 3% | |
| Load Regulation | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | |
| Setup,Rise,Hold up Time | 1.0s,30ms,80ms/230VAC(at full load) 2.0s,30ms,12ms/115VAC(at full load) | |||||
| Input | Rated Voltage Range | 100-240VAC | ||||
| Voltage Range | 90-264VAC | |||||
| Frequency Range | 50/60Hz | |||||
| AC Current | 0.2A/115VAC 0.21A/230VAC | |||||
| Inrush Current | Cold Start 30A/200us at 230VAC 50Hz Cold Start 15A/200us at 115VAC 50Hz | |||||
| Leakage Current | <0.25mA/230VAC | |||||
| Efficiency | 88% | 88.5% | 88% | 88.5% | 89% | |
| No Load Power Consumption | <0.1W | |||||
