12W Wall Mount Type

YS12A Series

Energy efficiency level Vl
Class ll Power Supply
3 Years Warranty
Universal AC input/Full range
No load power consumption < 0.1W
Protections: Short Circuit /Over Load /Over Voltage
-20~+70℃wide range working temperature

Model	Order P/N	YS12- 0602000A-D1J	YS12- 0751500A-D1J	YS12- 0901330A-D1J	YS12- 1201000A-D1J	YS12- 1500800A-D1J	YS12- 2400500A-D1J	YS12- 3600330A-D1J
Model	Safety Model No.	YS12-0602000	YS12-0751500	YS12-0901330	YS12-1201000	YS12-1500800	YS12-2400500	YS12-3600330
Output	DC Voltage	6V	7.5V	9V	12V	15V	24V	36V
	Rated Current	2A	1.5A	1.33A	1A	0.8A	0.5A	0.33A
	Rated Power	12W	11.25W	12W	12W	12W	12W	11.88W
	Ripple & Noise(max.)	75mVp-p	90mVp-p	120mVp-p	150mVp-p	240mVp-p	300mVp-p	360mVp-p
	Voltage Tolerance	± 5%	± 5%	± 5%	± 5%	± 5%	± 5%	± 5%
	Line Regulation	± 3%	± 3%	± 3%	± 3%	± 3%	± 3%	± 3%
	Load Regulation	± 5%	± 5%	± 5%	± 5%	± 5%	± 5%	± 5%
	Setup,Rise,Hold up Time	1.0s,30ms,25ms/230VAC(at full load) 2.0s,30ms,12ms/115VAC(at full load)
Input	Rated Voltage Range	100-240VAC
	Voltage Range	90-264VAC
	Frequency Range	50/60Hz
	AC Current	0.3A/115VAC 0.15A/230VAC
	Inrush Current	Cold Start 50A/200us at 230VAC 50Hz Cold Start 30A/200us at 115VAC 50Hz
	Leakage Current	<0.25mA/230VAC
	Efficiency	83%	83%	83.5%	83.5%	84%	84%	84.5%
	No Load Power Consumption	<0.1W
