YS120 SERIES
Energy efficiency level Vl
3 Years Warranty
Universal AC input/Full range
No load power consumption < 0.21W
Protections: Short Circuit /Over Load /Over Voltage
-30~+70℃wide range working temperature
90W Desktop Type
YS90
YS120 SERIES
Energy efficiency level Vl
3 Years Warranty
Universal AC input/Full range
No load power consumption < 0.21W
Protections: Short Circuit /Over Load /Over Voltage
-30~+70℃wide range working temperature
| Model | Order P/N | YS120-12012500 –□-M7B |
YS120-15010000 –□-M7B |
YS120-24006250 –□-M7B |
YS120-36004160 –□-M7B |
| Safety Model No. | YS120-12012500 | YS120-15010000 | YS120-24006250 | YS120-36004160 | |
| Output | DC Voltage | 12V | 15V | 24V | 36V |
| Rated Current | 12.5A | 10A | 6.25A | 4.16A | |
| Rated Power | 150W | 150W | 150W | 150W | |
| Ripple & Noise(max.) | 100mVp-p | 150mVp-p | 200mVp-p | 300mVp-p | |
| Voltage Tolerance | ± 5% | ± 5% | ± 5% | ± 5% | |
| Line Regulation | ± 3% | ± 3% | ± 3% | ± 3% | |
| Load Regulation | ± 5% | ± 5% | ± 5% | ± 5% | |
| Setup,Rise,Hold up Time | 1.0s,50ms,30ms/230VAC(at full load) 1.5s,50ms,20ms/115VAC(at full load) | ||||
| Input | Rated Voltage Range | 100-240VAC | |||
| Voltage Range | 90-264VAC | ||||
| Frequency Range | 50/60Hz | ||||
| AC Current | 2.7A/115VAC 1.5A/230VAC | ||||
| Inrush Current | Cold Start 60A/200us at 230VAC 50Hz Cold Start 40A/200us at 115VAC 50Hz | ||||
| Leakage Current | <0.75mA/230VAC | ||||
| Efficiency | 89% | 89.5% | 89% | 91.5% | |
| No Load Power Consumption | <0.21W | ||||
