YS10USB Series
Energy efficiency level Vl
Class ll Power Supply
3 Years Warranty
Universal AC input/Full range
No load power consumption < 0.1W
Protections: Short Circuit /Over Load /Over Voltage
-20~+60℃wide range working temperature
| Model | Order P/N | YS10-0501000-M | YS10-0502100-M |
| Safety Model No. | YS10-0501000 | YS10-0502100 | |
| Output | DC Voltage | 5V | 5V |
| Rated Current | 1A | 2.1A | |
| Rated Power | 5W | 10.5W | |
| Ripple & Noise(max.) | 75mVp-p | 75mVp-p | |
| Voltage Tolerance | ± 5% | ± 5% | |
| Line Regulation | ± 3% | ± 3% | |
| Load Regulation | ± 5% | ± 5% | |
| Setup,Rise,Hold up Time | 1.0s,40ms,60ms/230VAC(at full load) 2.0s,40ms,12ms/115VAC(at full load) | ||
| Input | Rated Voltage Range | 100-240VAC | |
| Voltage Range | 90-264VAC | ||
| Frequency Range | 50/60Hz | ||
| AC Current | 0.6A/100VAC 0.4A/240VAC | ||
| Inrush Current | Cold Start 70A/200us at 240VAC 50Hz Cold Start 35A/200us at 100VAC 50Hz | ||
| Leakage Current | <0.1mA/240VAC | ||
| Efficiency | 78% | 79.5% | |
| No Load Power Consumption | <0.1W | ||
