YS18E-M Series
Energy efficiency level Vl
Class ll Power Supply
3 Years Warranty
Universal AC input/Full range
No load power consumption < 0.1W
Protections: Short Circuit /Over Load /Over Voltage
-20~+60℃wide range working temperature
| Model | Order P/N | YS18-1202000EM-D1J | YS18-1501600EM-D1J | YS18-2401000EM-D1J | YS18-3600660EM-D1J | YS18-4800500EM-D1J |
| Safety Model No. | YS18-1202000EM | YS18-1501600EM | YS18-2401000EM | YS18-3600660EM | YS18-4800500EM | |
| Output | DC Voltage | 12V | 15V | 24V | 36V | 48V |
| Rated Current | 2A | 1.6A | 1A | 0.66A | 0.5A | |
| Rated Power | 24W | 24W | 24W | 24W | 24W | |
| Ripple & Noise(max.) | 100mVp-p | 150mVp-p | 200mVp-p | 240mVp-p | 360mVp-p | |
| Voltage Tolerance | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | |
| Line Regulation | ± 3% | ± 3% | ± 3% | ± 3% | ± 3% | |
| Load Regulation | ± 5% | ± 5% | ± 5% | ± 5% | ± 5% | |
| Setup,Rise,Hold up Time | 1.2s,25ms,50ms/230VAC(at full load) 2.5s,25ms,12ms/115VAC(at full load) | |||||
| Input | Rated Voltage Range | 100-240VAC | ||||
| Voltage Range | 90-264VAC | |||||
| Frequency Range | 50/60Hz | |||||
| AC Current | 0.7A/115VAC 0.55A/230VAC | |||||
| Inrush Current | Cold Start 120A/200us at 230VAC 50Hz Cold Start 45A/200us at 115VAC 50Hz | |||||
| Leakage Current | <0.1mA/230VAC | |||||
| Efficiency | 82.5% | 87.5% | 88% | 88.5% | 89% | |
| No Load Power Consumption | <0.1W | |||||
