YEP200 Series
Universal AC Input/ Full Range
Built-in Active PFC Function
Cooling by free air convection
High efficiency up to 89.5%
Over voltage category ll
Protections: Short circuit/Over load/Over voltage/Over temperature
LED indicator for power on
Three years warranty
| Part Number | DC Voltage | Rated Current(max.) | Rated Power | Efficiency | Ripple & Noise | Max Capacitive Load | Voltage ADJ Range |
| YEP200-5 | 5V | 40A | 200W | 85% | 150mVp-p | 8000uF | 4.5~5.5V |
| YEP200-7.5 | 7.5V | 26.7A | 200.25W | 88.5% | 150mVp-p | 6000uF | 6~9V |
| YEP200-12 | 12V | 16.7A | 200.4W | 88% | 150mVp-p | 4000uF | 10~13.2V |
| YEP200-13.5 | 13.5V | 14.9A | 201.15W | 88% | 150mVp-p | 3500uF | 12~15V |
| YEP200-15 | 15V | 13.4A | 201W | 89% | 150mVp-p | 3300uF | 13.5~18V |
| YEP200-24 | 24V | 8.4A | 201.6W | 88.5% | 150mVp-p | 1500uF | 20~26.4V |
| YEP200-27 | 27V | 7.5A | 202.5W | 88.5% | 200mVp-p | 1200uF | 26~31.5V |
| YEP200-36 | 36V | 5.56A | 200.16W | 88.5% | 220mVp-p | 1000uF | 32.4~39.6V |
| YEP200-48 | 48V | 4.2A | 201.6W | 89% | 240mVp-p | 470uF | 41~56V |
| YEP200-60 | 60V | 3.36A | 201.6W | 89.5% | 300mVp-p | 470uF | 52~66V |
